1080P Driver Monitor System Driving Status Detection

1080P Driver Monitor System Driving Status Detection

DMS31

STONKAM® 1080P Driver Monitor System can help monitor and alert driver when drowsiness or distraction is detected, which aims to add driving safety. Working with our MDVR Systems will get better effects for effective fleet management! (Contact for more details.)

Inquire Now

Leave your message and contact details, we will try to get back to you!

Features

Support AHD/CVBS/fast ethernet output and RTSP, ISO17215 and other network protocols. Strong compatibility and wide application range
Detect and alarm driver unsafe behaviors: fatigue detection, distraction detection, phone call detection, smoking detection, no driver detection and non-mask detection
Driver identification, up to 400 certifications
Seamless integration with MDVR, realtime alarm and video uploading for abnormal driving behavior
With built-in high definition alarm recording (1920 x 1080 resolution, 20 seconds synchronous recording when alarm triggered)
With built-in GPS module, recording actual speed and location
With built-in WIFI module, the device can be easily calibrated and configured via Android APP by connecting the device WIFI
With built-in infrared light, driver status can be effectively detected with low light condition. The driver could be wearing sunglasses and detected too
With built-in 2W loudspeaker, good alarm sound effect
Supports up to 128G Micro SD card, can record 120 hours in total, and allows loop recording

Power supply	10~36V DC
Power consumption	Max 4W
Built-in camera module parameters	FHD 1920x1080P/25f or 1920x1080P/30f
Video output	1CH, AHD, 1920x1080/25f or 1920x1080/30f
Video compression	H.264
Video record resolution	720P or 1080P
Recording parameters	The recording file is in MP4 format, 128G Micro SD card
Audio compression	ADPCM
WIFI module parameters	802.11b/g/n 150Mbps
Operation temperature	-20°C ~ +60°C
Storage temperature	-40°C ~ +85 ℃
Dimensions	110x86.5x64 mm
Weight	200g
GPS	YES
Speaker power	Max. 2W
Output mode	AHD/CVBS/Fast ethernet
Network protocol	RTSP/ISO17215

Why do you need STONKAM® Driver Monitoring System?

Distracted and drowsy driving are leading causes of a large number of road accidents. They’re dangerous and may happen to anyone, no matter how experienced a driver is. But with Driver Fatigue Monitoring System, you can constantly monitor driving status and promptly receive alarms upon unsafe driving behaviors, and therefore effectively reduce the risk of accidents caused by distraction and drowsiness.

STONKAM® Driver Monitoring System

Make Your Driving a Safe Journey

STONKAM® Driver Monitoring System, based on facial feature recognition, collects the driver’s facial images and head postures through the camera, and then compares them with various abnormal driving behavior models in the database to identify the current driver status.

driver fatigue

If there is any abnormal driving behavior (such as fatigue, distraction, smoking, phone call), audible alarm and visual alarm will be given.

driver monitoring camera

driving alarm

driving monitoring device

vehicle driver monitoring system

driver monitoring system

driver fatigue monitoring system

Easily set up the device on APP via Wi-Fi

The Driver Fatigue Monitoring System can connect to the Android APP designed by STONKAM® on mobile phone via Wi-Fi. Device configuration, file uploading and other functions can be easily done on the APP.

driver camera system

HD Video recording by 128GB SD card

When the system detects abnormal driving behaviors, it will automatically give alarms and record for about 20 seconds of 720P/1080P HD resolution on 1 x 128GB (Max.) Micro SD card.

driver fatigue

Built-in GPS enables the system to automatically start or stop working

The system records the vehicle position and speed through GPS when alarm recording occurs. And it automatically stops working when the speed is lower than the starting speed set by the APP (0-25km/h), you don’t have to manually turn off the system when it’s not needed, for example, when it’s severe traffic jam.

driver monitoring camera

Perfect seamless integration with STONKAM® Mobile DVR for fleet management
When working with our MDVR, the MDVR system can automatically record alarm events and upload relevant files; alarm info will simultaneously pop up on PC client/ mobile Android APP for fleet administrators to analyze the driving situation of vehicles.

driving monitoring device

Applications

STONKAM®Driver Monitoring System is applicable to various vehicles, such as buses, trucks, and construction machinery, etc.
