4.3 inches Vision Systems
(Model:MO-144D, CW-664)
4.3 inches Vision Systems
Features
4.3" Carrearview Mirror LCD Monitor (MO-144D):
  • Mounting position: inner side of vehicle windshield (rear mirror position of vehicles)
  • Mirror viewing angle: rear viewing angle adjustable
  • Shatterproof standard:2.84G
  • Working condition: Performs in rugged conditions; operating temperature: -20℃~+70℃
  • Distance label can be turned on or off, and can be adjusted up and down
  • Backlighting for buttons: automatic backlighting in dim light.
  • Backlighting for screen: Automatic backlighting when in dim light longer than 5s (Lighting brightness can be set up and saved)
  • Power supply for camera, easy installation
  • Wide voltage input: support 12V and 24V system


Truck Camera (CW-664):
  • Camera angle is adjustable
  • Mirror/ Normal image switch
  • IP rating : IP69K
  • Night vision distance: 10m ; Night vision can auto switch to B/W mode. Good night vision performance, small noise and no color aberration.
  • With audio
  • Lens angle: CMOS: 120°; CCD: 92°, 120°, 150°
Specification
4.3 inch Rearview Mirror Monitor (MO-144D)
1. TV system: PAL/NTSC/AUTO
2. Language system: 8 languages selectable
3. Video input: 2 video inputs and power supply for camera
4. Distance label: Can be adjusted up and down
5. Auto trigger: 2 camera trigger wires,once triggered, automatically switches to its corresponding
6. camera
7. Frame ratio: 16:9
8. Dot pitch: 0.198(H)×0.198(V)
9. Resolution: 480(H)×3(RGB)×272(V) Brightness: 800 cd/m2
10. Contrast: 500:1
11. Viewing angle: U:50°,D:70°, L/R:70°
12. Power consumption: 3W
13. Power supply: DC12-32V
14. Operating temperature: -20℃~+70℃
15. Storage temperature: -30℃~+80℃
Applications
4.3 inches Vision Systems-Application
Distance Label
4.3 inches Vision System-Distance Label
